9L MUFFLE FURNACE – SLAB ELEMENT(909)

Description

    Features:

• Scientific muffle furnaces are ideal for a wide range of applications where high temperatures are required

* Robustly constructed and fitted with high-quality components for reliable operation

* Electronic P.I.D temperature control with digital indication of set and process value

* Solid state switching for improved reliability and rapid response

* Independent sensors for control and safety using type n duplex thermocouple
* Maximum continuous operating temperature 1150°C

* Easily replaceable side wall mounted slab elements

* Automatic cut out switch on door opening deactivates element

* Door mounted temperature sampling port for easy validation, thus retaining heat inside the chamber.

* Robust construction with slide out control panel for ease of service

* High thermal efficiency ceramic insulation coupled to double skin construction ensures cool to touch exterior panels
* Out and up door with vertically counterbalanced action protects operator from potential burns

Note:
* Prior to ordering please advise on application
* Ashing option available
* Optional programmable controllers

Additional information

Download instruction manual
