SLX-3: 7x-45x Stereomicroscope/dissecting microscope low magnification
R14,874.00 Excl. VAT
Trinocular stereozoom microscope, 7x-5x.
- Additional information
Optika Italy, Trinocular stereomicroscope, 7x – 45x. This is a low magnification microscope for viewing larger objects. Observation mode: Brightfield.
Head: Binocular head, 45° inclined.
Interpupillary distance: Adjustable.
Dioptric adjustment: Both eyepieces.
Eyepieces: WF10x/21 mm, high eyepoint, secured by screw and with rubber cups.
Objective: Parfocal achromatic zoom 0.7x…4.5x (6.43:1 ratio) with anti-fungus treatment.
Stand: High-grade, precision fixed with handle and focus.
Focusing: Rack and pinion focusing mechanism.
Illumination: EcoLED™ swiveling incident and transmitted, with brightness control, rechargeable batteries. Color temperature: 6,300 K. Multi-plug 100-240Vac/5Vdc external power supply.
Working distance: 100 mm.
|Dimensions||50 × 42 × 31 cm|
External, 220volt, 50Hz & rechargeable batteries Ni-MH (3x, AA size)
Yes, EcoLED, 6,300 K
YES, EcoLED, 6,300K
Coarse travel: 110mm with adjustable tension
Fixed arm, with handle
With specimen clips, 100mm diameter plate, either frosted for transmitted light or black/white for incident light
Trinocular, 45 degree inclination, 51-75 interpupillary distance, dioptric adjustment on both tubes, 30mm tube diameter
10 x magnification & field number 21mm, with rubber cap, 23mm diameter for micrometer glass
Instructions in the box for standard binocular stereomicroscope & download from Optika.
